ID511CC0E00A
WEBOWT
851109H
ID511 Exd
Product Features
Order No.: 851109H
Model No.: ID511CC0E00A
EXD ID511, Silver Cast Aluminium EXD Box, IIB T6,
Two serial ports(RS232+RS232/RS485),
MODBUS-RTU, EtherCAT,
7-bit LED,
Basic,
110V/220VAC without power cord,
6000e
Configurates with various explosion-proof scale: EXPHC/EXPHS
Supports for multiple shell types
Has a wide selection of interface boards and supports various application software packages.
Abundant PLC communication interface
7-bit LED segment code display
Support one analog scale input, up to 12 load cells
CPA 6000e certified precision, up to 150,000d display division
Have passed OIML & CE certification
Standard with two serial ports: RS232+RS232/485 or RS232+RS485+LAN Port(EtherNet)
Standard support MODBUS-RTU, MODBUS-TCP(Only for LAN Port version)
PLC Options
PROFIBUS-DP(Siemens PLC)
CC-link (Mitsubishi PLC)
PROFINET (LAN Port x2, built-in switch, Siemens PLC)
EtherNet/IP (LAN Port x2, built-in switch, Rockwell PLC, Delta PLC)
4-20mA(16-bit precision DAC)
4-20mA x2(16-bit precision DAC)
I/O Options:
IN x8 / OC OUT x12
IN x 8 / Relay OUT x 12
Multi-calibration:
Support up to 5-point test weight calibration
No test weight calibration
Remote calibration via PROFIBUS-DP, PROFINET, EtherNet/IP, etc.
Main Applications:
Basic Weighing
Lower limit and upper limit level checking
Support two speed preset point control and 8 simple comparison outputs
Working power supply:
Support 85-264VAC or 24VDC, and the maximum power consumption of the whole machine is less than 6W
Overall explosion proof certification of indicator and isolation explosion-proof box
Built in 6-wires load cell safety barrier
