Customized Solutions-Paint and Tinting Batching System
Home » Customized Solutions-Paint and Tinting Batching System

Products

ID510-Panel

ID510 Panel Process controller for packaging filling dosing
ID510 Process Controller
ID510 Series
  • ID510 Panel -Back View
    ID510 Panel-Back View
  • ID510 Panel-Left Side View
    ID510 Panel-Left Side View
  • ID510 Harsh -Front View
    ID510 Harsh -Front View
  • ID510 Harsh -Back View
    ID510 Harsh -Back View
  • ID510Harsh-Standard01
    ID510Harsh-Standard01
  • ID510Harsh-Wall Type Installation
    ID510Harsh-Wall Type Installation
  • ID510Harsh-Customized-with SS keyboard01
    ID510Harsh-Customized-with SS keyboard
  • ID510 Process Controller Box
    ID510 Process Controller Box
6_03
Brief Introduction
  1. "2.7" OLED dot matrix graphic display, supporting Chinese and English switching
  2. It supports 1-way analog scale platform access, and supports up to 12 sensors
  3. CPA 6000e certified accuracy, up to 150000 display divisions
  4. European OIML certification and CE certification
  5. Two serial ports RS232+RS232/485 are standard, or two serial ports RS232+RS485 plus an EtherNet port
  6. The standard configuration supports MODBUS-RTU, MODBUS-TC (only network port version)
  7. PLC communication interface options
  8. PROFIBUS-DP(Siemens PLC) ·CC-LINK(Mitsubishi PLC)
  9. 1 channel 4-20mA(16 bit precision DAC) · 2 channel 4-20mA(16 bit precision DAC)
  10. PROFINET(dual network port ,built in switch ,Siemens PLC)
  11. EtherNet/IP(dual network port ,built in switch ,Rockwell PLC ,Delta PLC)
  12. I/O(I/O option): 8 inputs and 12 transistor outputs /  8 inputs and 12 relay outputs
  13. Multiple calibration mode: Up to 5-point weight calibration is supported ·Weight free calibration
  14. Remote calibration through PLC communication interface
  15. Support application:   Basic weighing version/packaging version/weight checking version/filling version/batching version
  16. The working power supply supports AC 85-264VAC or DC 24VDC, and the maximum power consumption of the whole machine
Drawing
ID510 Drawing and Installation
Configuration
ID510 Configuration
Configuration Category
  • ID510 Panel
  • ID510 Harsh
  • ID510 Batching PAC
  • ID510 Filling PAC
  • ID510 High-speed Check Weighing
  • ID510 Bagging & Packaging PAC
Replacement Parts
Download

Manual

  • ID510_Technical_Manual_Basic_App_R2.0_20220825.pdf

Technical Specification

  • ID510_Technical_Manual_Basic_App_R2.0_20220825.pdf

Certificates

  • OIML-Certificate-R76_2006-A-DK2-2022.07-ID510 ID511 ID551PN.pdf

Typical Application
