7-bit LED display Supports 1 analog scale input, with a maximum of 12 load cells Metrological approval (CPA) 6000e certified accuracy, OIML: 6000e. Have got OIML & CE certificates Standard with serial ports x 2 RS232+RS232/485 or serial ports x 2 RS232+RS485 with one LAN port Standard supports MODBUS-RTU, MODBUS-TCP (only supported by the ethernet version) Optional PLC communication interface PROFIBUS-DP (Siemens PLC) PROFINET (dual LAN ports, built-in switch, Siemens PLC) EtherNet/IP (dual LAN ports, built-in switch, Rockwell PLC, Delta PLC) CC-Link (Mitsubishi PLC) 4-20mA (16-bit precision DAC) x 1 4-20mA (16-bit precision DAC) x 2 I/O (input/output options) In x 8 / OC Out x 12 In x 8 / Relay Out x 12 Multiple calibration modes Supports up to 5-point calibration Calibration without weights Remote calibration through PLC communication interface Application supports Basic weighing version Supports dual-speed preset point control and 8 simple comparison outputs Lower/upper limit material level detection The working power supports AC 85-264VAC or DC 24VDC, and the maximum power consumption of the complete machine is less than 6W;
7-bit LED display Supports 1 analog scale input, with a maximum of 12 load cells Metrological approval (CPA) 6000e certified accuracy, OIML: 6000e. Have got OIML & CE certificates Standard with serial ports x 2 RS232+RS232/485 or serial ports x 2 RS232+RS485 with one LAN port Standard supports MODBUS-RTU, MODBUS-TCP (only supported by the ethernet version) Optional PLC communication interface PROFIBUS-DP (Siemens PLC) PROFINET (dual LAN ports, built-in switch, Siemens PLC) EtherNet/IP (dual LAN ports, built-in switch, Rockwell PLC, Delta PLC) CC-Link (Mitsubishi PLC) 4-20mA (16-bit precision DAC) x 1 4-20mA (16-bit precision DAC) x 2 I/O (input/output options) In x 8 / OC Out x 12 In x 8 / Relay Out x 12 Multiple calibration modes Supports up to 5-point calibration Calibration without weights Remote calibration through PLC communication interface Application supports Basic weighing version Supports dual-speed preset point control and 8 simple comparison outputs Lower/upper limit material level detection The working power supports AC 85-264VAC or DC 24VDC, and the maximum power consumption of the complete machine is less than 6W;
7-bit LED display Supports 1 analog scale input, with a maximum of 12 load cells Metrological approval (CPA) 6000e certified accuracy, OIML: 6000e. Have got OIML & CE certificates Standard with serial ports x 2 RS232+RS232/485 or serial ports x 2 RS232+RS485 with one LAN port Standard supports MODBUS-RTU, MODBUS-TCP (only supported by the ethernet version) Optional PLC communication interface PROFIBUS-DP (Siemens PLC) PROFINET (dual LAN ports, built-in switch, Siemens PLC) EtherNet/IP (dual LAN ports, built-in switch, Rockwell PLC, Delta PLC) CC-Link (Mitsubishi PLC) 4-20mA (16-bit precision DAC) x 1 4-20mA (16-bit precision DAC) x 2 I/O (input/output options) In x 8 / OC Out x 12 In x 8 / Relay Out x 12 Multiple calibration modes Supports up to 5-point calibration Calibration without weights Remote calibration through PLC communication interface Application supports Basic weighing version Supports dual-speed preset point control and 8 simple comparison outputs Lower/upper limit material level detection The working power supports AC 85-264VAC or DC 24VDC, and the maximum power consumption of the complete machine is less than 6W;
7-bit LED display Supports 1 analog scale input, with a maximum of 12 load cells Metrological approval (CPA) 6000e certified accuracy, OIML: 6000e. Have got OIML & CE certificates Standard with serial ports x 2 RS232+RS232/485 or serial ports x 2 RS232+RS485 with one LAN port Standard supports MODBUS-RTU, MODBUS-TCP (only supported by the ethernet version) Optional PLC communication interface PROFIBUS-DP (Siemens PLC) PROFINET (dual LAN ports, built-in switch, Siemens PLC) EtherNet/IP (dual LAN ports, built-in switch, Rockwell PLC, Delta PLC) CC-Link (Mitsubishi PLC) Scale x 1 4-20mA (16-bit precision DAC) Scales x 2 4-20mA (16-bit precision DAC) I/O (input/output options) In x 8 / OC Out x 12 In x 8 / Relay Out x 12 Multiple calibration modes Supports up to 5-point calibration Calibration without weights Remote calibration through PLC communication interface Application supports Basic weighing version Supports dual-speed preset point control and 8 simple comparison outputs Lower/upper limit material level detection The working power supports AC 85-264VAC or DC 24VDC, and the maximum power consumption of the complete machine is less than 6W;
7-bit LED display Supports 1 analog scale input, with a maximum of 12 load cells Certification: CPA 6000e, division up to 150,000 Standard serial ports x 2 RS232 + RS232/485, or serial ports x 2 RS232 + RS485 with one LAN port Standard supports MODBUS-RTU, MODBUS-TCP (only supported by the ethernet version) Optional PLC communication interface PROFIBUS-DP (Siemens PLC) • CC-link (Mitsubishi PLC) PROFINET (dual LAN ports, built-in switch, Siemens PLC) EtherNet/IP (dual LAN ports, built-in switch, Rockwell PLC, Delta PLC) scale x 1 4-20 mA (16-bit precision DAC) • scales x 2 4-20 mA (16-bit precision DAC) Optional I/O (input/output) In x 8 / OC Out x 12 Multiple calibration modes Supports up to 5-point weight calibration • Calibration without weight Remote calibration via PLC communication interface Application supports Basic weighing version • Lower/upper limit level detection Supports dual-speed preset point control and 8 simple comparison outputs Built-in load cell safety barrier supports direct connection to scale platforms in Zone 1 and Zone 2 Working power supply DC 24VDC, maximum power consumption of the complete machine is less than 6 W
7-bit LED display Supports 1 analog scale input, with a maximum of 12 load cells Certification: CPA 6000e, division up to 150,000 Standard with serial port x 1 (RS232/485), 2 LAN ports, and 1 high precision weighing AD Standard supports for MODBUS-RTU and MODBUS-TCP (for single LAN port version only) Optional PLC communication interface PROFINET (dual LAN ports, built-in switch, Siemens PLC), certified by siemens PN consistency test EtherNet/IP (dual LAN ports, built-in switch, rockwell PLC, Delta PLC) CC-link IE FB (Mitsubishi PLC) EtherCAT (HIAS PLC) Optional I/O (input/output) In x 4 / MOS Out x 6. Multiple calibration modes Supports up to 5-point weight calibration Calibration without weights Remote calibration through PLC communication interface Calibration with material Application supports Basic weighing version Supports dual-speed preset point control and 8 simple comparison outputs Lower/upper limit material level detection The working power supports AC 85-264VAC or DC 24VDC, and the maximum power consumption of the complete machine is less than 6W
7-bit LED display Supports 1 analog scale input, with a maximum of 12 load cells Certification: CPA 6000e, division up to 150,000 Standard with serial port x 1 (RS232/485), 2 LAN ports, and 1 high precision weighing AD Standard supports for MODBUS-RTU and MODBUS-TCP (for single LAN port version only) Optional PLC communication interface PROFINET (dual LAN ports, built-in switch, Siemens PLC), certified by siemens PN consistency test EtherNet/IP (dual LAN ports, built-in switch, rockwell PLC, Delta PLC) CC-link IE FB (Mitsubishi PLC) EtherCAT (HIAS PLC) Optional I/O (input/output) In x 4 / MOS Out x 6. Multiple calibration modes Supports up to 5-point weight calibration Calibration without weights Remote calibration through PLC communication interface Calibration with material Application supports Basic weighing version Supports dual-speed preset point control and 8 simple comparison outputs Lower/upper limit material level detection The working power supports AC 85-264VAC or DC 24VDC, and the maximum power consumption of the complete machine is less than 6W
7-bit LED display Supports 1 analog scale input, with a maximum of 12 load cells Certification: CPA 6000e, division up to 150,000 Standard with serial port x 1 (RS232/485), 2 LAN ports, and 1 high precision weighing AD Standard supports for MODBUS-RTU and MODBUS-TCP (for single LAN port version only) Optional PLC communication interface PROFINET (dual LAN ports, built-in switch, Siemens PLC), certified by siemens PN consistency test EtherNet/IP (dual LAN ports, built-in switch, rockwell PLC, Delta PLC) CC-link IE FB (Mitsubishi PLC) EtherCAT (HIAS PLC) Optional I/O (input/output) In x 4 / MOS Out x 6. Multiple calibration modes Supports up to 5-point weight calibration Calibration without weights Remote calibration through PLC communication interface Calibration with material Application supports Basic weighing version Supports dual-speed preset point control and 8 simple comparison outputs Lower/upper limit material level detection The working power supports AC 85-264VAC or DC 24VDC, and the maximum power consumption of the complete machine is less than 6W
